	IP8T-RB-DNL	IP8T-NC.2	IP5VD-NC.2	IP5T-NV	IP4T-NL	IP4T-NC	IP4MVD-NC	IP2BLPR-NC
Form Factor	Turret	Turret	Dome	Turret	Turret	Turret	Mini Dome	Bullet
Max Resolution	8 MP	8 MP	5 MP	5 MP	4 MP	4 MP	4 MP	2 MP
Sensor	1/2.8" CMOS	1/2.7" CMOS	1/2.7" CMOS	1/1.8" CMOS	1/3" CMOS		1/3" CMOS	1/2.8" CMOS
Lens	[email protected]	[email protected]	[email protected]	[email protected]	[email protected]	[email protected]	[email protected]	[email protected]
NightVue				✔
NightLight	✔				✔
NightColor		✔	✔		✔	✔	✔	✔
Illumination	0.0005 Lux	0.005 Lux	0.003 Lux	0.0003 Lux	0.003 Lux	0.003 Lux	0.003 Lux	0.001 Lux
IR Range	Up to 30m (98ft)	Up to 30m (98ft)	Up to 30m (98ft)	Up to 30m (98ft)	Up to 30m (98ft)	Up to 30m (98ft)	Up to 30m (98ft)	Up to 50m (164ft)
Advanced Analytics	✔					✔	✔
Smart Analytics			✔
Smart IR		✔		✔		✔	✔
LED Defender	✔
WDR	130dB	120dB	120dB	120dB	120dB	120dB	120dB
9:16 Corridor Mode	✔	✔	✔	✔	✔	✔	✔
Dewarping	✔
Edge Storage	Micro SD, up to 512 GB	Micro SD, up to 256 GB	Micro SD, up to 256 GB	Micro SD, up to 256 GB	Micro SD, up to 128 GB	Micro SD, up to 256 GB	Micro SD, up to 256 GB	Micro SD, up to 128 GB
Built-in Mic	✔	✔	✔	✔	✔	✔
Built-in Speaker	✔				✔
Field of View (H)	106.5°	112.9°	112.9°	110.4°	112.9°	101.1°	101.1°
Field of View (V)	57.9°	59.1°	59.1°	60.5°	59.1°	55.3°	55.3°
Field of View (D)	132°	121.2°	121.2°	1215.2°	121.2°	111.1°	111.1°
IP Rating	IP67	IP67	IP67	IP67	IP67	IP67	IP67	IP67
Vandal Resistant			IK10				IK10	IK10
Dimensions (Ø x H)	Φ4.4” x 3.7”	Φ4.6” x 3.8”	Ø4.3” x 3.3”	Ø4.6” x 4.2”	Ø4.6” x 3.8”	Ø4.6” x 3.8”	Ø4.3” x 2.4”	15.2” x 4.9” x 5.1"
Weight	0.97lb	0.79lb	0.79lb	1.06lb	0.66lb	0.77lb	0.82lb	4.41lb
Availible Color	White Black	White Black	White Black	White	White	White Black	White	White

	TVI5T-NC-NL	TVI5T-NC-NL-BK	TVI2T-NC-NL	TVI2T-NC-NL-BK
Form Factor	Turret	Turret	Turret	Turret
Max Resolution	5 MP	5 MP	2 MP	2 MP
Sensor	1/2.7" CMOS	1/2.7" CMOS	1/3.0" CMOS	1/3.0" CMOS
Lens	[email protected]	[email protected]	[email protected]	[email protected]
NightLight	✔	✔	✔	✔
NightColor	✔	✔	✔	✔
Illumination	0.005 Lux	0.005 Lux	0.003 Lux	0.003 Lux
IR Range	Up to 40m (131.2ft)	Up to 40m (131.2ft)	Up to 40m (131.2ft)	Up to 40m (131.2ft)
WDR	DWDR	DWDR	DWDR	DWDR
Built-in Mic	✔	✔	✔	✔
Built-in Speaker
Field of View (H)	110.0°	110.0°	100.9°	100.9°
Field of View (V)	57.0°	57.0°	55.5°	55.5°
Field of View (D)	130.0°	130.0°	121.8°	121.8°
IP Rating	IP67	IP67	IP67	IP67
Vandal Resistant
Dimensions (Ø x H)	Ø4.3” x 3.8”	Ø4.3” x 3.8”	Ø4.3” x 3.8”	Ø4.3” x 3.8”
Weight	0.53lb	0.53lb	0.53lb	0.53lb

Comming Soon

	DVR16.3	DVR8.3	DVR4.3
Channels	16	8	4
SATA	1 SATA	1 SATA	1 SATA
Capacity	Up to 16TB	Up to 16TB	Up to 16TB
Advanced Analytics	✔	✔	✔
Decoding Format	Ultra 265, H.265, H.264	Ultra 265, H.265, H.264	Ultra 265, H.265, H.264
RCA Audio Input	1 Channel	1 Channel	1 Channel
RCA Audio Output	1 Channel	1 Channel	1 Channel
Liveview Display	1/4/6/8/9	1/4/6/8/9	1/4
Recording Resolution	Up to 16 MP	Up to 16 MP	Up to 16 MP
Power Supply	DC 52V/1.8A	DC 52V/1.8A	DC 48V/1.35A
Dimensions (WxDxH)	10.2"x8.7"x1.8"	10.2"x8.7"x1.8"	10.2"x8.7"x1.8"
Weight	2.43 lb	2.43 lb	2.43 lb
